AE30-LT Non-silicone Thermal Gel
Use Range:
AE30-LT is a soft, non‑silicone thermalgap filler, featuring high thermal conductivity, low interfacial thermal resistance and excellent thixotropy. It is ideal for applications with large gap tolerances. Filled between heat-generating electronic components and heat sinks/housings, this material ensures tight contact, reduces thermal resistance, dissipates heat rapidly and effectively, thereby extending the service life and enhancing the reliability of electronic components. It can be applied manually or with dispensing equipment.
To request a sample of our Non-silicone Thermal Gel (Silicone-free Thermal Liquid Gap Filler) or inquire about more product information, please email us at sales3@u-sheen.com or request a product sample.
◆ Power Supply Units (PSUs)
◆ LED Modules
◆ Engine Control Units (ECUs)
◆ Gaming Consoles and Laptops
◆ Hard disks, mobile phones
◆ Optical precision equipment
◆ Mobile and communication equipment
This product is non-toxic and should be stored and transported as a non-hazardous material.
● Packed in drums: 5KG, 10KG, 20KG
Dongguan Sheen Electronic Technology Co., Ltd.
◆ Founded: 2008
◆ Team: 200 employees
◆ Facility: 20,000㎡
◆ Focus: R&D and production of functional materials
◆ Strengths: Efficient, collaborative team
◆ Achievements: Key supplier to leading global manufacturers
◆ Applications: Telecom, Automotive, Medical, Computing, Industrial , Military
◆ Certifications: ISO9001:2015, ISO14001:2015, IATF16949:2016
Product Description
SHEEN's AE Series Non-silicone Thermal Gel are renowned for their outstanding performance characteristics, which include:
◆ Silicone-free.
◆ Excellent thermal conductivity, available in 3.0±0.3W/m·K.
◆ High softness and compressibility, providing low assembly stress, ideal for delicate and sensitive electronic components.
◆ Excellent flame resistance, achieving a UL94 V-0 rating.
◆ Outstanding electrical insulation properties, with dielectric strength up to 6 kV/mm.
◆ No cracking or dripping, ensuring good stability in both high and low-temperature environments.
◆ Can be precisely controlled for thickness and shape using automated equipment.
◆ Complies with RoHS, Halogen-Free, and REACH environmental & safety standards.
◆ Silicone-free.
◆ Excellent thermal conductivity, available in 3.0±0.3W/m·K.
◆ High softness and compressibility, providing low assembly stress, ideal for delicate and sensitive electronic components.
◆ Excellent flame resistance, achieving a UL94 V-0 rating.
◆ Outstanding electrical insulation properties, with dielectric strength up to 6 kV/mm.
◆ No cracking or dripping, ensuring good stability in both high and low-temperature environments.
◆ Can be precisely controlled for thickness and shape using automated equipment.
◆ Complies with RoHS, Halogen-Free, and REACH environmental & safety standards.
【Applications】
◆ Power Supply Units (PSUs)
◆ LED Modules
◆ Engine Control Units (ECUs)
◆ Gaming Consoles and Laptops
◆ Hard disks, mobile phones
◆ Optical precision equipment
◆ Mobile and communication equipment
◆ Automobile engine control equipment
◆ High-end industrial control and medical electronics and other fields
◆ High-end industrial control and medical electronics and other fields
Properties
| Properties | Unit | AE30-LT | Test Method |
|---|---|---|---|
| Color | - | Gray | Visual |
| Thermal Conductivity | W/m·K | 3.0 ± 0.3 | ASTM D5470 |
| Thermal Resistance(@50psi) | ℃*in2/W | ≤0.085 | ASTM D5470 |
| Extrusion speed | g/min |
30±10
|
30ccEFDcartridges
0.095”orifice 90psi
|
| Minimum Interface Thickness | mm | 0.11 | - |
| Density | g/cm³ | 3.0±0.2 | ASTM D792 |
|
Breakdown voltage
(@AC,2mm) |
kV/mm | > 6.0 | ASTM D149 |
| Operating Temp. | ℃ | -40 ~ 150 | - |
| Oil Drainage Radius (@25℃，72h) |
mm | ≤3 | - |
| RoHS | - | PASS | IEC 62321 |
| Halogen | - | PASS | EN 14582 |
| REACH | - | PASS | EN 14372 |
【Storage & Transportation】
Store in a well-ventilated, cool, and dry area, away from open flames.This product is non-toxic and should be stored and transported as a non-hazardous material.
【Packaging】
● Dispensing Syringes: 30CC/300CC● Packed in drums: 5KG, 10KG, 20KG
【Shelf Life】
12 monthsAbout Us
