Product Description
Applications
◆ Cooling chassis component
◆ Rack or other type of heat dissipation
◆ Heat pipe assembly
◆ Motor control
◆ Telecom hardware
Videos
Product Parameters
TIV800-30 | ||
Item | Test | Test method |
Colour | White | Visual |
Main ingredient | Silicone resin | *** |
Exterior | Semi-flow | *** |
Dry time (minutes) | 10~20 | *** |
Curing condition/H | Natural curing(24H) | *** |
Density (g/cm3) | 3.05+/-0.1 | ASTM D297 |
Hardness Shore A) | 50+/-5 | ASTM D2240 |
Bond strength (Mpa) | ≥1.5 | *** |
Temperature range (℃) | -50~200 | *** |
Breakdown voltage /(KV/mm) | 20 | ASTM D149 |
Volume resistivity (Ω·cm) | 3.0*1013 | ASTM D257 |
Thermal Conductivity (W/m-K) | 3.0 | ASTM D5470 |
RoHS | PASS | IEC 62321 |
Halogen | PASS | EN14582 |
REACH | PASS | EN14372 |
Test fixtures using ASTM D5470. Recorded values include interface thermal resistance. These values are for reference only. The actual application performance is directly related to the applied surface roughness, flatness and pressure.
TIV series Thermal glue | ||||
Sheen glue series | Thermal conductivity | ShoreA hardness | Dielectric Breakdown Voltage | Bond strength(Mpa) |
TIV800-10 | 1.0 W/mK | 40-60 | >5KV/AC/mm | >1.5 |
TIV800-12 | 1.2 W/mK | 40-60 | >5KV/AC/mm | >1.5 |
TIV800-15 | 1.5 W/mK | 40-60 | >5KV/AC/mm | >1.5 |
TIV800-20 | 2.0 W/mK | 40-60 | >5KV/AC/mm | >1.5 |
TIV800-30 | 3.0 W/mK | 50+/-5 | >5KV/AC/mm | >1.5 |
Customization Ability
About Us
Dongguan Sheen Electronic Technology Co., Ltd is a high-tech enterprise which dedicates to develop, produce and sale of thermal conductive materials and thermal insulation materials, For now the main products are thermally conductive pad, thermally conductive gel, thermal grease, phase change thermal grease, phase change thermal interface materials, thermally conductive tape, foam silicone sheet, thermal silicone adhesive, thermal insulation materials, they are widely used in cell phone, power supplies, LED lights, computers, automotive electronic, network communications, electrical and mechanical equipment, instrumentations, electrical and electronic fields and so on.
